Network Camera User Manual
26
zoom, etc.
For IE (Internet Explorer) users, plug-ins as webcomponents and quick time are
selectable. And for Non-IE users, webcomponents, quick time, VLC or MJPEG are
selectable if they are supported by the web browser.
Note:
If you are using Google Chrome 45 and its above version or Mozilla Firefox 52 and its
above version, plug-in installation is not required. But Picture and Playback functions
are hidden. To use mentioned function via web browser, change to their lower
version, or change to Internet Explorer 8.0 and its above version.
PTZ Control:
Perform panning, tilting and zooming actions of the camera. Control the light and the
wiper (only available for cameras supporting PTZ function).
Preset/Patrol Settings:
Set/call/delete the presets or patrols for PTZ cameras.
Starting Live View
In the live view window as shown in Figure 4-2, click on the toolbar to start the
live view of the camera.
Live View Toolbar
Table 4-1 Descriptions of the Toolbar
Icon
Description
/
Start/Stop all live view.
The window size is 4:3.
The window size is 16:9.
/
The original widow size or original ratio.
Self-adaptive window size.
, ,
The window division 1x1, 2x2, or 3x3.
, , , etc.
Live view with the different video streams.
Supported video streams vary according to camera models.

HIKVISION DS-2CD6924G0-IHS Specifications

General

Form factor	Dome
Mounting type	Ceiling
Product color	Black
Bluetooth	-
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
Sample rate	48 kHz
Bit rate range	16 - 192 Kbit/s
Audio formats supported	G.711, MP2L2, G.722.1, G.726, PCM
Total megapixels	- MP
Maximum resolution	6480 x 1080 pixels
Video formats supported	H.264, H.265
Supported graphics resolutions	1920 x 1080 (HD 1080), 3840 x 2160
Number of cameras	1
Fixed focal length	6 mm
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	20 m
Number of illumination LEDs	4
DC output voltage	12
Power source type	DC, PoE
Sensor type	CMOS
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Pan range	0 - 355 °
Tilt angle range	0 - 90 °
Minimum illumination	0.003 lx
Type	IP security camera
Languages support	English
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB

Weight and Dimensions

Depth	207.63 mm
Width	189.5 mm
Height	206.62 mm
Weight	3000 g
Package type	Box
Package depth	261 mm
Package width	340 mm
Package height	293 mm
Package weight	5000 g
