HIKVISION DS-2CE16H0T-ITPF User Manual

Drill Template
Hole A: for cables routed through the ceiling
screw hole 1: for Mounting Base
1
1
1
A
Screw
Hole
Cable
Hole
Figure 2-14 Drill Template
Note:
Cable hole is required, when adopting the ceiling
outlet to route cables.
3. Loosen the set screws with a hex wrench (supplied)
to remove the bubble.
Figure 2-15 Remove the Bubble
4. Fix the mounting base on the ceiling with supplied
screws.
Figure 2-16 Fix the Mounting Base
5. Route the cables through the cable hole, or the side
opening.
6. Connect the corresponding cables, such as power
cord, and video cable.
7. Power on the camera to check whether the image
on the monitor is gotten from the optimum angle. If
not, adjust the camera according to the figure below
to get an optimum angle
Adjusting Screw
0° to 355°
0° to 75°
0° to 355°
Figure 2-17 Type I Camera 2-Axis Adjustment
1). Loosen the tilt adjusting screw to adjust the tilt
position [0° to 75°].
