User Manual of E Series Network Mini PTZ camera
© Hikvision
4
Chapter 2 Network Connection
Before you start:
 If you want to set the network mini PTZ camera via a LAN (Local Area Network), please refer
to Section 2.1.
 If you want to set the network mini PTZ camera via a WAN (Wide Area Network), please
refer to Section 2.2.
2.1 Setting the Network Mini PTZ camera over the LAN
Purpose:
To view and configure the mini PTZ camera via a LAN, you need to connect the network mini PTZ
camera in the same subnet with your computer, and install the SADP or client software to search
and change the IP of the network mini PTZ camera.
For the detailed introduction of SADP, please refer to Appendix 1.
2.1.1 Wiring over the LAN
The following figures show the two ways of cable connection of a network mini PTZ camera and a
computer:
Purpose:
 To test the network mini PTZ camera, you can directly connect the network mini PTZ camera
to the computer with a network cable as shown in Figure 2-1.
 Refer to the Figure 2-2 to set the network mini PTZ camera over the LAN via a switch or a
router.
Network Cable
Figure 2-1 Connecting Directly
Speed Dome
Network Cable
Switch or Router
PC
Network Cable
Figure 2-2 Connecting via a Switch or a Router
