HIKVISION DS-2DE4A404IW-DE User Manual

User Manual of E Series Network Mini PTZ camera
© Hikvision
32
Figure 4-16 Set Playback Time
Figure 4-17 Progress Bar
The different colors of the video on the progress bar stand for the different video types as shown
in Figure 4-18.
Figure 4-18 Video Types
Downloading Video Files
Steps:
1. Click on the playback interface. The pop-up menu is shown in Figure 4-19.
2. Set the start time and end time. Click Search. The corresponding video files are listed on the
left.
Figure 4-19 Video Downloading interface
3. Check the checkbox in front of the video files that you need to download.
4. Click to download the video files.

HIKVISION DS-2DE4A404IW-DE Specifications

General

Brand	HIKVISION
Model	DS-2DE4A404IW-DE
Category	Security Camera
Language	English
