User Manual of E Series Network Mini PTZ camera
© Hikvision
3. Click tab to enter the arming schedule setting interface. The arming
schedule configuration is the same as the setting of the arming schedule for motion detection.
Refer to Step 2 Set the Motion Detection Area in Section 5.2.1 Configuring Motion Detection.
4. Click tab to select the linkage method taken for the video loss alarm, notify
surveillance center, send email and trigger alarm output are selectable. Refer to Step 2 Set the
Arming Schedule for Motion Detection in Section 5.2.1 Configuring Motion Detection.
5. Check the checkbox to select the linkage method taken for the tampering. Notify surveillance
center, send email and trigger alarm output are selectable. Please refer to Step 3 Set the
Alarm Actions for Motion Detection in Section 5.2.1 Configuring Motion Detection.
6. Click to save the settings.
5.2.3 Configuring Alarm Input
Steps:
1. Enter the Alarm Input Settings interface:
Configuration > Event > Basic Event > Alarm Input
2. Choose the alarm input No. and the Alarm Type. The alarm type can be NO (Normally Open)
and NC (Normally Closed).
3. Edit the name in to set a name for the
alarm input (optional).
Figure 5-18 Alarm Input Settings
