HIKVISION DS-6904UDI User Manual

DS-6900UDI Series HD Video and Audio Decoder User Manual
DS-6900UDI Decoder Us er Manua l
81
Controlling Remote Screen via RSC Server
Enter the Video Wall interface and click in the Camera list area, or click on
Device Management interface to add the RSC server.
Add RSC Server
Enter the parameters to add the RSC server. Please refer to Chapter 7.1 Adding an Encoding
/Decoding Device to add the RSC server.
The default user name is admin and the server password is 12345 and we highly recommend
you to change the default password to avoid the security problem.
The successfully added RSC server is listed in the camera list.
Added RSC Server
On the camera list, drag the RSC server to the video output window.

HIKVISION DS-6904UDI Specifications

General

PTZ control	Yes
Channels quantity	4 channels
Maximum frame rate	30 fps
Alarm input channels	8
Supported video modes	720p, 1080p
Audio formats supported	AAC
Video formats supported	H.264, H.264+, H.265, H.265+, M-JPEG, MPEG4
Maximum video resolution	3840 x 2160 pixels
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 3840 x 2160
RS-232 ports	1
BNC output ports	2
Number of HDMI outputs	4
Ethernet LAN (RJ-45) ports	18
Power consumption (max)	70 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Cabling technology	10/100/1000BaseE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Product color	Black

Weight and Dimensions

Depth	311 mm
Width	440 mm
Height	44.5 mm
Weight	5200 g
