HIKVISION DS-7100NI-Q1 Series Quick Start Guide

Network Video Recorder Quick Start Guide
11
1.1.3 DS-7600NI Series
Figure 1. 5 DS-7600NI Series
Table 1. 3 Panel Description
1.2 Rear Panel
1.2.1 DS-9600NI and DS-8600NI Series
Figure 1. 6 DS-9600NI-I8 and DS-8600NI-K8 Series
Figure 1. 7 DS-9600NI-I16 Series
No.
Name
Connections
1
POWER
Turns green when NVR is powered up.
2
HDD
Flickers red when data is being read from or written to HDD.
3
Tx/Rx
Flickers blue when network connection is functioning properly.
4
USB Interface
Universal Serial Bus (USB) port for additional devices such as USB
mouse and USB Hard Disk Drive (HDD).

HIKVISION DS-7100NI-Q1 Series Specifications

General

Brand	HIKVISION
Model	DS-7100NI-Q1 Series
Category	Network Hardware
Language	English
