HIKVISION DS-7108NI-Q1/M User Manual

4. Set the
connuous main stream/sub-stream recording parameters for the camera. Refer to
Congure Recording Parameter for details.
5. Go to Conguraon → Record → Schedule .
6. Select recording type as Event. Refer to Edit Schedule for details.
Edit Schedule
Steps
1.
Go to
Conguraon → Record → Schedule .
Figure 5-17 Recording Schedule
Connuous
Connuous recording.
Event
Recording is triggered by events.
2. Select a camera in Camera No..
3. Turn on Enable.
4.
Congure the recording schedule.
Edit
Schedule
a. Click Edit.
b. Select a day to congure in Weekday.
c. To set an all-day recording schedule, check All Day and select schedule type.
d. To set other schedules, uncheck All Day, and set Start/End Time and
schedule type.
Note
Up to 8 periods can be congured for each day. And the me periods
cannot be overlapped with each other.
e. Click OK to save the sengs and go back to upper level menu.
Network Video Recorder User Manual
33

HIKVISION DS-7108NI-Q1/M Specifications

General

DC voltage	12 V
Power supply type	DC
Power consumption (typical)	10 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Video input channels	8 channels
USB 2.0 ports quantity	2
VGA (D-Sub) output ports	1
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Maximum HDD capacity	6000 GB
Video compression formats	H.264, H.265

Weight and Dimensions

Depth	225 mm
Width	260 mm
Height	48 mm
Weight	1000 g
