The HQHI series DVR support up to 3 MP resultion for the first channel of DVR with 4-ch
video inputs, the first 2 channels of DVR with 8-ch video inputs and the first 4 channels of
DVR with 16-ch video inputs. When the 3 MP signal input is connected to the supported
channel, the recording resolution will be adjusted to 3 MP and the frame rate will be
adjusted to 12 fps automatically if the resolution and frame rate is not confiugred manually.

The DS-7200/7300/7600/8100/9000HUHI-F/N series support up to 3 MP resolution of all the
channels.

For HQHI and DS-7200HUHI-F/N series DVR, if the 3 MP camera is connected to the channel
which supports up to 1080p signal input, it will switch to 1080p signal input. When the 3
MP signal is switched to 1080p signal, the PAL will be switched to 1080p/25Hz, and the
NTSC will be switched to 1080p/30Hz.

For all the –F series DVR, four kinds of analog signal inputs including HDTVI (including 3 MP,
1080p and 720p signal), AHD, HDCVI and CVBS can be connected. The analog signal inputs
can be recognized automatically and can be mixed randomly.

If the configured encoding resolution conflicts with the resolution of the front-end camera,
the encoding parameters will adjust automatically to meet the front-end camera. E.g., if the
resolution of the front-end camera is 720p, then the encoding resolution of the main
stream will adjust to 720p automatically.

The resolution of 960 × 1080 (1080P Lite) is available when the 1080P Lite is enabled in the
Record>Advanced Settings interface (refer to Chapter 5.12 Configuring 1080P Lite).

Please refer to the Appendix-Specifications for the supported resolutions of different
models.
Bitrate Type: Set the bitrate type to be Variable or Constant.
Video Quality: Set the video quality of recording, with 6 levels configurable.
The Stream Type, Resolution, Bitrate Type and Video Quality are not configurable for the Main
Stream (Event) of the IP Camera.
Frame Rate: Set the frame rate of recording.
For DS-7200/7300/7600/8100/9000HUHI-F/N series, when 3 MP signal input is connected, the
frame rate of both the main stream and sub-stream cannot exceed 15 fps.
Max. Bitrate Mode: Set the mode to General or Custom.
Max Bitrate (Kbps): Select or customize the maximum bit rate for recording.
Max. Bitrate Range Recommended: A recommended max. bit rate range is provided for
reference.
Max. Average Bitrate (Kbps): Set the max. average bit rate which refers to the average
amount of data transferred per unit of time.

HIKVISION DS-7116HGHI-F1 Specifications

General

Bit rate	64 Kbit/s
Certification	CE
Product color	White
Channels quantity	16 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711 μ-law
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Audio input	1x RCA
BNC input ports	16
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	20 W

Weight and Dimensions

Depth	210 mm
Width	285 mm
Height	45 mm
Weight	1200 g
