HIKVISION DS-7116HGHI-F1 User Manual

Digital Video Recorder User Manual
294
Model
DS-7204HUHI-F2
/N
DS-7208HUHI-F2
/N
DS-7216HUHI-F2
/N
Sub-stream:
WD1/4CIF@12fps;
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video bit rate
32 Kbps to 10 Mbps
Audio output
1-ch, RCA (Linear, 1 KΩ)
Audio bit rate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous
playback
4-ch
8-ch
16-ch
Network
management
Remote
connections
128
Network
protocols
TCP/IP, PPPoE, DHCP, Cloud P2P, DNS, DDNS, NTP, SADP, NFS,
iSCSI, UPnP™, HTTPS, ONVIF
Hard disk
SATA
2 SATA interfaces
Capacity
Up to 6 TB capacity
External
interface
Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the audio input)
Network
interface
1, RJ45 10M/100M
self-adaptive
Ethernet interface
1, RJ45 10M/100M/1000M self-adaptive
Ethernet interface
USB interface
2 × USB 2.0
Front panel: 1× USB 2.0
Rear panel: 1×USB 3.0
Serial interface
RS-485 (half-duplex)
Alarm in/out
4/1
8/4
16/4
General
Power supply
12 VDC
Consumption
(without HDD)
≤ 15 W
≤ 20 W
≤ 25 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF)

HIKVISION DS-7116HGHI-F1 Specifications

General

Bit rate	64 Kbit/s
Certification	CE
Product color	White
Channels quantity	16 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711 μ-law
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Audio input	1x RCA
BNC input ports	16
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	20 W

Weight and Dimensions

Depth	210 mm
Width	285 mm
Height	45 mm
Weight	1200 g
