User Manual of Network Video Recorder
32
Figure 2. 7 Network Configuration
 A 10 /100 Mbps self-adaptive Ethernet interface for DS-7604/7608NI, DS-7104/7108NI and
DS-7100NI-SL series NVR; and a 10 /100/1000 Mbps self-adaptive Ethernet interface for other
models.
 For the DS-7600NI-SE/N(P) series NVR which has the PoE or built-in switch network interfaces, the
internal NIC IPv4 address should be configured for the cameras connecting to the PoE or built-in
switch network interface of the NVR.
4. Click Next button to enter the Advanced Network Parameter interface. You can enable UPnP, enable
DDNS and set other ports according to your need.
Figure 2. 8 Advanced Network Parameters
5. Click Next button after you configured the advanced network parameters. Then you will enter the EZVIZ
Cloud P2P interface. Configure the EZVIZ Cloud P2P according to your need.

HIKVISION DS-7116NI-SN/P Specifications

General

Number of users	128 user(s)
Maximum resolution	1920 x 1080 pixels
Video input channels	4 channels
Supported resolutions	1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Audio RCA inputs	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Power over Ethernet (PoE)	Yes
Copper ethernet cabling technology	10BASE-T, 100BASE-T
Power over Ethernet (PoE) ports quantity	4
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	4 TB
Number of HDDs installed	0
Output voltage	48 V
Power consumption (max)	35 W
Power consumption (typical)	6 W
Product color	White
Rack capacity	1U
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No

Weight and Dimensions

Depth	205 mm
Width	255 mm
Height	45 mm
Weight	1000 g
