User Manual of DS-7200-ST Series DVR
92
Figure 5. Patrol Management Menu
3. In the Patrol Management menu, you may:
• Configure Patrol:
1. Select a Patrol Number to set.
2. Select valid presets (See Customize Presets) and click the Set button to enter the Patrol
configuration menu. A sequence should have at least 2 valid presets.
3. Set the Key Point No., Duration, and Speed (Figure 6). The Key Point No. determines
the order at which the PTZ will follow while cycling through the patrol. The Duration
refers to the time span to stay at the corresponding key point. The Speed defines the rate
at which the PTZ will move to the current preset.
Figure 6. Patrol Configuration Menu
4. Click OK to return to Patrol Management menu and repeat steps 2-3 to configure other
key points.
5. After all key points have been configured, click the defined key point No. and then click
Add button to complete the settings.
6. Click OK button to save settings and exit the current menu.
• Clear Patrol:
1. Select a valid Patrol Number.
2. Click the Clear button to delete patrol.
• Call Patrol:
1. Select a valid Patrol Number.
2. Click the Start button to call the patrol, and select the Stop button to stop the patrol, as
shown in Figure 7.
