Trigger Alarm Output
The alarm output can be triggered by the normal and smart events.
Steps
1.
Go to Linkage Acon interface of the alarm input or event detecon.
2.
Click Alarm Output Linkage.
3.
Select the alarm outputs to trigger.
4.
Go to
Conguraon → Event → Normal Event → Alarm Output .
5.
Select an alarm output item from the list. Refer to Alarm Output for details.
Congure
PTZ Linkage
Video recorder can trigger the PTZ acons (e.g., call preset/patrol/paern) when the alarm event,
or VCA detecon events occur.
Steps
1.
Go to Linkage Acon interface of the alarm input or VCA detecon.
2.
Select PTZ Linkage.
3.
Select the camera to perform the PTZ
acons.
4.
Select the preset/patrol/paern No. to call when the alarm events occur.
Figure 6-26 PTZ Linkage
Note
You can set one PTZ type only for the linkage acon each me.
