Digital Video Recorder User Manual
191
Chapter 11 VCA Search
With the configured VCA detection, the device supports the VCA search for the behavior search,
face search, plate search, people counting and heat map results.
The DS-7100 series DVR do not support the VCA search.
11.1 Face Search
Purpose
When there are detected face picture captured and saved in HDD, you can enter the Face Search
interface to search the picture and play the picture related video files according to the specified
conditions.
Before you start
Please refer to Chapter 10.1 Face Detection for configuring the face detection.
Step 1 Enter the Face Search interface.
Menu>VCA Search> Face Search
Step 2 Select the camera (s) for the face search.
Figure 11-1 Face Search
Step 3 Specify the start time and end time for searching the captured face pictures or video files.
Step 4 Upload the pictures from your local storage device for matching the detected face pictures.

HIKVISION DS-7216HQHI-F1/N Specifications

General

Video input channels	16 channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Power consumption (typical)	30 W
Voltage	12 V
Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Analog signal format system	NTSC, PAL
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
