HIKVISION DS-7216HQHI-F1/N User Manual

Digital Video Recorder User Manual
223
Figure 13-15 Array Settings Interface
Step 2 Select an array and click to delete the array.
Figure 13-16 Confirm Array Deletion
Step 3 In the pop-up message box, click Yes button to confirm the array deletion.
Deleting array will cause to delete all the data in the array.
13.4 Checking and Editing Firmware
Purpose
You can view the information of the firmware and set the background task speed on the Firmware
interface.
Step 1 Enter the Firmware interface to check the information of the firmware, including the
version, maximum physical disk quantity, maximum array quantity, auto-rebuild status, etc.
Figure 13-17 Firmware Interface
Step 2 You can set the Background Task Speed in the drop-down list.
Step 3 Click the Apply button to save the settings.

HIKVISION DS-7216HQHI-F1/N Specifications

General

Video input channels	16 channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Power consumption (typical)	30 W
Voltage	12 V
Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Analog signal format system	NTSC, PAL
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
