HIKVISION DS-7216HQHI-F1/N User Manual

Digital Video Recorder User Manual
263
Figure 17-18 User List
Step 3 Click to delete the selected user account.
17.5.3 Editing a User
Purpose
For the added user accounts, you can edit the parameters.
Step 1 Enter the User Management interface.
Menu >Configuration>User
Step 2 Select the user to be edited from the list, as shown in Figure 17-18.
Step 3 Click the icon to enter the Edit User interface, as shown in Figure 17-19.
Figure 17-19 Edit User Interface
Step 4 Edit the corresponding parameters.


 Operator and Guest
You can edit the user information, including user name, password, permission level and
MAC address. Check the checkbox of Change Password if you want to change the password,
and input the new password in the text field of Password and Confirm. A strong password
is recommended.

HIKVISION DS-7216HQHI-F1/N Specifications

General

Video input channels	16 channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Power consumption (typical)	30 W
Voltage	12 V
Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Analog signal format system	NTSC, PAL
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
