18.1.19 DS-9000HUHI-F8/N
Model
DS-9004HUHI-F8
/N
DS-9008HUHI-F8/
N
DS-9016HUHI-F8
/N
Video/Audio
input
Video
compression
H.264+/H.264
Analog video
input
4-ch 8-ch 16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
Turbo HD
input
1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60, 3 MP
AHD input 720p30, 720p25, 1080p25, 1080p30
HDCVI input
720p30, 720p25, 1080p25, 1080p30
CVBS input Support
IP video input
6-ch (up to 10-ch) 10-ch (up to 18-ch) 18-ch (up to 32-ch)
Up to 8 MP resolution
H.265/H.264+/H.264
Audio
compression
G.711u
Audio input
4-ch 8-ch 16-ch
RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704
× 480
HDMI1/VGA
output
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
HDMI2
output
1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 ×
1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60Hz
Encoding
resolution
3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame rate
Main stream:
3 MP@15fps;
1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

HIKVISION DS-7216HQHI-F1/N Specifications

General

Video input channels	16 channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Power consumption (typical)	30 W
Voltage	12 V
Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Analog signal format system	NTSC, PAL
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
