HIKVISION DS-7216HQHI-F1/N User Manual

Digital Video Recorder User Manual
38
Figure 1-9 Remote Control
The keys on the remote control closely resemble the ones found on the front panel. Refer to Table
1-7, they include:
Table 1-7 Description of the IR Remote Control Buttons
No. Name Description
1 POWER
Power on/off the device.
Power on/off the device by pressing and holding the
button for 5 seconds.
2 MENU Button
Press the button to return to the main menu (after
successful login).
Press and hold the button for 5 seconds will turn off
audible key beep.
In PTZ Control mode, the MENU button will start wiper
(if applicable).
In Playback mode, it is used to show/hide the control

HIKVISION DS-7216HQHI-F1/N Specifications

General

Video input channels	16 channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Power consumption (typical)	30 W
Voltage	12 V
Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Analog signal format system	NTSC, PAL
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
