HIKVISION DS-7332HQHI-K4 User Manual

Network Video Recorder User Manual
15
Set a Patrol .............................................................................................................. 79
Call a Patrol ............................................................................................................. 80
Set a Pattern ............................................................................................................ 81
Call a Pattern ........................................................................................................... 82
Set Linear Scan Limits .............................................................................................. 82
Call Linear Scan ....................................................................................................... 83
One-touch Park ....................................................................................................... 83
Auxiliary Functions ........................................................................................................... 84
Chapter 7 Storage ............................................................................................................................ 85
Storage Device Management ........................................................................................... 85
Install the HDD ........................................................................................................ 85
Add the Network Disk ............................................................................................. 85
Configure eSATA for Data Storage ........................................................................... 87
Storage Mode ................................................................................................................... 88
Configure HDD Group ............................................................................................. 88
Configure HDD Quota.............................................................................................. 90
Recording Parameters ...................................................................................................... 91
Main Stream ............................................................................................................ 91
Sub-Stream .............................................................................................................. 92
Picture ..................................................................................................................... 92
Configure Advanced Recording Settings ................................................................. 92
Configure Recording Schedule ......................................................................................... 93
Configure Continuous Recording ..................................................................................... 95
Configure Motion Detection Triggered Recording ........................................................... 95
Configure Event Triggered Recording ............................................................................... 96
Configure Alarm Triggered Recording .............................................................................. 96
Configure Picture Capture ................................................................................................ 96
Configure Holiday Recording and Capture ..................................................................... 97
Configure Redundant Recording and Capture ............................................................... 99
Configure 1080p Lite .................................................................................................... 100
Enable the 1080P Lite Mode ............................................................................... 100
Disable the 1080P Lite Mode .............................................................................. 101
Chapter 8 Disk Array .................................................................................................................... 102
Create Disk Array ............................................................................................................ 102
Enable RAID ........................................................................................................... 102

HIKVISION DS-7332HQHI-K4 Specifications

General

Bit rate	64 Kbit/s
Product color	Black
Remote viewing	Yes
Maximum frame rate	30 fps
Audio formats supported	G.711 μ-law
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Number of simultaneously playbacked channels	16 channels
Audio input	5
BNC input ports	32
BNC output ports	1
Alarm input channels	16
Video input channels	32 channels
Alarm output channels	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Maximum HDD capacity	10000 GB
AC input voltage	100 - 240 V
Power supply type	AC
Power consumption (max)	74 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	440 mm
Height	70 mm
Weight	7000 g
