HIKVISION DS-7608NI-Q2/8P User Manual

Network Video Recorder User Manual
123
Figure 7-10 Result of Event Search
Step 6 Export the video files. Please refer to step5 of Chapter 7.1.2 Backing up by Normal Video
Search for details.
7.1.4 Backing up Video Clips
Purpose:
You may also select video clips in playback mode to export directly during Playback, using USB
devices (USB flash drives, USB HDDs, USB writer), SATA writer or eSATA HDD.
Step 1 Enter Playback interface.
Please refer to Chapter 6.1 Playing Back Record Files.
Step 2 During playback, use buttons or in the playback toolbar to start or stop clipping
record file (s); or use the button to capture pitcures.
Step 3 Click the to enter the file management interface.
Figure 7-11 Video Clips or Captured Pictures Export Interface

HIKVISION DS-7608NI-Q2/8P Specifications

General

DHCP client	Yes
Input bandwidth	80 Mbit/s
Maximum frame rate	60 fps
Maximum resolution	3840 x 2160 pixels
Alarm input channels	1
Video input channels	8 channels
Supported resolutions	1024 x 768, 1280 × 720, 1280 × 1024, 1920 × 1080, 1600 × 1200, 3840 × 2160
Video recording modes	720p, 1080p
Wi-Fi	No
HDD capacity	2000 GB
HDD interface	Serial ATA
Maximum storage capacity	16 TB
Number of HDDs supported	2
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Power over Ethernet (PoE) ports quantity	8
Product color	Black
Rack capacity	1U
LED indicators	LAN, Power, Status
AC input voltage	100 - 240 V
Power consumption (typical)	15 W
Total Power over Ethernet (PoE) budget	80 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	315 mm
Width	385 mm
Height	52 mm
Weight	3000 g
