Network Video Recorder User Manual
96
Figure 6. 6 Event Search Interface
4. Select the minor type of VCA from the drop-down list. (Please refer to Chapter 9 VCA Alarm for the
details of VCA detection types).
For configuring the VCA recording, please refer to Chapter 5.4 Configuring VCA Event Recording and
Capture; and for details of VCA detection types, please refer to Chapter 9 VCA Alarm.
5. Select the camera (s) for searching, and set the Start time and End time.
6. Click Search button to get the search result information. You may refer to the right-side bar for the result.
7. Select a result item and click button to play back the file.
Pre-play and post-play can be configured.
8. Enter the Synch Playback interface to select the camera (s) for synchronous playback.
Figure 6. 7 Synch Playback Interface
9. Enter the playback interface.
The toolbar in the bottom part of playback interface can be used to control playing process.

HIKVISION DS-7732NI-E4 Specifications

General

Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	16
Video input channels	32 channels
Alarm output channels	4
HDMI output	Yes
Audio RCA inputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
HDD interface	Serial ATA
Maximum storage capacity	24 TB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	4000 g
