Network Video Recorder User Manual
191
Figure 11-7 People Counting Interface
Step 7 You can click the Export button to export the statistics report in excel format.
11.5 Heat Map
Purpose:
Heat map is a graphical representation of data represented by colors. The heat map function is
usually used to analyze the visit times and dwell time of customers in a configured area.
The heat map function must be supported by the connected IP camera and the corresponding
configuration must be set.
Step 1 Enter the Heat Map interface.
Menu > VCA Search > Heat Map
Step 2 Select the camera for the heat map processing.
Step 3 Select the report type to Daily Report, Weekly Report, Monthly Report or Annual Report.
Step 4 Set the statistics time.

Table of Contents

Other manuals for HIKVISION DS-8616NI-K8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-8616NI-K8 and is the answer not in the manual?

HIKVISION DS-8616NI-K8 Specifications

General IconGeneral
Audio input2
RS-232 interfaceYes
Alarm input channels16
Video input channels16 channels
Alarm output channels4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100, 1000 Mbit/s
Supported network protocolsTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
Internal SATA ports quantity8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
AC input voltage100 - 240 V
Power supply typeAC
AC input frequency50 - 60 Hz
Power consumption (typical)200 W
Ethernet interface typeGigabit Ethernet
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Input bandwidth160 Mbit/s
Supported resolutions3840 × 2160 1920 × 1080 1600 × 1200 1280 × 1024 1280 × 720 1024 × 768
Audio formats supportedG.711 A-law, G.711 μ-law, G.726
Video formats supportedH.264, H.264+, H.265, H.265+, MPEG4
Maximum video resolution3840 x 2160 pixels
Video compression formatsH.264, H.265
HDD capacity- GB
HDD interfaceSATA, eSATA
Maximum HDD capacity6000 GB
Maximum storage capacity8 TB
Number of HDDs installed-
CertificationCE, FCC, CB, IC, RCM, KCC, ICE-003
Product colorBlack
Rack capacity2U
Weight and Dimensions IconWeight and Dimensions
Depth470 mm
Width445 mm
Height90 mm
Weight8000 g
