HIKVISION DS-8616NI-K8 User Manual

Network Video Recorder User Manual
21
No.
Name
Function Description
Turns on/off PTZ light (if applicable) in PTZ
control mode.
Switches between play and reverse play in
playback mode.
F2/ AUX
Cycles through tab pages.
Switches between channels in synchronous
playback mode.
MENU/WIPER
Returns to the Main menu (after successful
login).
Presses and holds the button for five seconds to
turn off audible key beep.
Starts wiper (if applicable) in PTZ control mode.
Shows/hides the control interface in playback
mode.
PREV/FOCUS-
Switches between single screen and
multi-screen mode.
Adjusts the focus in conjunction with the
A/FOCUS+ button in PTZ control mode.
PTZ/IRIS-
Enters the PTZ Control mode.
Adjusts the iris of the PTZ camera in PTZ control
mode.
8
Control
Buttons
DIRECTION
Navigates between different fields and items in
menus.
In the playback mode, use the Up and Down
buttons to speed up and slow down recorded
video. Use the Left and Right buttons to select
the next and previous video files.
Cycles through channels in live view mode.
Controls the movement of the PTZ camera in
PTZ control mode.
ENTER
Confirms selection in any of the menu modes.
Checks the checkbox fields.
Plays or pauses the video playing in playback

HIKVISION DS-8616NI-K8 Specifications

General

Audio input	2
RS-232 interface	Yes
Alarm input channels	16
Video input channels	16 channels
Alarm output channels	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
Internal SATA ports quantity	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
AC input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Ethernet interface type	Gigabit Ethernet
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Input bandwidth	160 Mbit/s
Supported resolutions	3840 × 2160 1920 × 1080 1600 × 1200 1280 × 1024 1280 × 720 1024 × 768
Audio formats supported	G.711 A-law, G.711 μ-law, G.726
Video formats supported	H.264, H.264+, H.265, H.265+, MPEG4
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.265
HDD capacity	- GB
HDD interface	SATA, eSATA
Maximum HDD capacity	6000 GB
Maximum storage capacity	8 TB
Number of HDDs installed	-
Certification	CE, FCC, CB, IC, RCM, KCC, ICE-003
Product color	Black
Rack capacity	2U

Weight and Dimensions

Depth	470 mm
Width	445 mm
Height	90 mm
Weight	8000 g
