170

User Manual of Digital Video Recorder

10.3 Managing eSATA

Purpose:

When there is an external eSATA device connected to DVR, you can configure eSATA for the use of Record or

Export, and you can manage the eSATA in the DVR.

Steps:

Enter the Advanced Record Settings interface.

Menu >Record>Advanced

Select the eSATA type to Export or Record from the dropdown list of

eSATA

Export

: use the eSATA for backup. Refer to

Backup using eSATA HDDs

Chapter 7.1.1 Backing up by

Normal Video Search

for operating instructions.

Record:

use the eSATA for record. Refer to the following steps for operating instructions.

Figure 10. 11 Set eSATA Mode

When the eSATA type is selected to Record, enter the HDD Information interface.

Menu > HDD>General

Edit the property of the selected eSATA, or initialize it is required.

Two storage modes can be configured for the eSATA when it is used for Record. Please refer to

Chapter 10.4

Managing HDD Group

and

Chapter 10.5 Configuring Quota Mode

for details.

Figure 10. 12 Initialize Added eSATA
