HIKVISION DS-9016HQHI-SH User Manual

User Manual of Digital Video Recorder
6
Product Key Features
General
 Connectable to HD-TVI and analog cameras;
 Connectable to the Coaxitron camera/dome with long transmission distance;
 Connectable to IP cameras;
The IP camera connection is not supported by DS-7100;
 Each channel supports dual-stream. Main stream supports up to 1080P resolution and sub-stream
supports up to WD1 resolution;
The DS-7100-E1 and DS-7200-E1/E2 support up to 720P resolution.
 Independent configuration for each channel, including resolution, frame rate, bit rate, image quality,
etc.
 Encoding for both video stream and video & audio stream; audio and video synchronization during
composite stream encoding;
 Watermark technology.
Local Monitoring
 HDMI/VGA output at up to 1920*1080 resolution;
 1/4/6/8/9/16/25/36 screen live view is supported, and the display sequence of screens is adjustable;
 Live view screen can be switched in group and manual switch and automatic cycle live view are also
provided, the interval of automatic cycle can be adjusted;
 Quick setting menu is provided for live view;
 The selected live view channel can be shielded;
 Motion detection, video-tampering detection, video exception alarm, video loss alarm and VCA alarm
functions;
 Privacy mask;
 Several PTZ protocols supported; PTZ preset, patrol and pattern;
 Zooming in/out by clicking the mouse and PTZ tracing by dragging mouse.
HDD Management
 For DS-7100HGHI-SH/E1, DS-7104HQHI-SH and DS-7200HGHI-E1 series, 1 SATA hard disk can
be connected;
For DS-7200HGHI&HQHI-SH and DS-7200HGHI-E2 series, up to 2 SATA hard disks can be
connected;
For DS-7300HGHI&HQHI-SH series, 4 SATA hard disks and 1 eSATA disk can be connected;
For DS-8100/9000-SH series, 8 SATA hard disks and 1 eSATA disk can be connected.
 Each disk with a maximum of 6TB storage capacity.
 8 network disks (NAS /IP SAN disks) can be connected;
 Support eSATA disks for recording or backup;
 Support S.M.A.R.T. and bad sector detection;
 Support HDD sleeping function;
 HDD property: redundancy, read-only, read/write (R/W);
 HDD group management;
 HDD quota management; different capacity can be assigned to different channels.

HIKVISION DS-9016HQHI-SH Specifications

General

Product color	Black
Channels quantity	16 channels
Total storage capacity	0 GB
Video compression formats	H.264
Graphical user interface (GUI)	Yes
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Audio input	8
RS-485 ports	1
BNC input ports	16
USB 2.0 ports quantity	3
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, HTTPS, DDNS, RTP, RTSP, SNMP
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Power requirements	100-240 VAC, 47-63Hz
Power consumption (typical)	65 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
Dimensions (WxDxH)	445 x 470 x 90 mm
