HIKVISION DS-D5022FN-C User Manual

Hikvision 22-Inch Monitor User Manual
UM Hikvision 22-Inch Monitor 090721NA 13
OSD Settings
OSD parameters concern the display effect of OSD such as position, transparency, and rotation.
Figure 9, OSD Settings
OSD Parameters
Parameter
Description
Horizontal
Ranges from 0 to 100
Vertical
Ranges from 0 to 100
Transparency
Off/Weak/Medium/Strong
OSD Time Out
Off/5 S/15 S/30 S/1 Min
OSD Rotation
Off/On
NOTE: If OSD Rotation is enable, the OSD will rotate 270 degrees clockwise, and the point
(0, 0) is at the bottom-left corner.
Software Version
Figure 10, Version

HIKVISION DS-D5022FN-C Specifications

General

Panel type	-
Color gamut	72 %
Pixel pitch	0.0831 x 0.241 mm
Screen shape	Flat
Response time	6.5 ms
Backlight type	Direct LED
Display diagonal	21.5 \
Display technology	LED
Maximum refresh rate	60 Hz
Viewable size, vertical	260.28 mm
Contrast ratio (typical)	3000:1
Viewable size, horizontal	478.656 mm
Display brightness (typical)	250 cd/m²
HDMI	Yes
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	22 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 90 %
Panel mounting interface	75 x 75 mm
Package depth	403 mm
Package width	644 mm
Package height	108 mm
Package weight	3800 g
Product color	Black
Market positioning	Business

Weight and Dimensions

Bezel width (side)	19.06 mm
Depth (with stand)	200.2 mm
Width (with stand)	492.356 mm
Height (with stand)	390.11 mm
Weight (with stand)	2500 g
Bezel width (bottom)	30.87 mm
Depth (without stand)	43.88 mm
Height (without stand)	289.68 mm
