HIKVISION DS-D5043FL-B User Manual

Table 2-1 Descripon of Menu Operaons
1 Press MENU and the main menu appears on the screen, such as image mode,
audio sengs, VGA parameters, etc.
2 Press ▲/▼/◄/► to select a submenu.
3 Press OK to conrm the submenu.
4 Press ▲/▼ to select parameters.
5 Press ◄/► to set the parameters.
6 Press MENU to complete the sengs and back to the main menu interface.
OSD Sengs
You can set the language and OSD duraon on the menu.
Enter Menu
Sengs page: Menu → Menu Sengs , and then set language, OSD duraon, and
OSD blending.
Figure 2-2 OSD Sengs
Language
Supports Chinese & English menu switch.
OSD Duraon
Refers to the display me of the menu aer it is not used. Press ◄ or ► to adjust the OSD
duraon to: Always On/5 Sec/15 Sec/30 Sec.
OSD Blending
Refers to the OSD transparency. You can adjust the blending value to: High/Middle/Low/O.
LCD Monitor User Manual
6

HIKVISION DS-D5043FL-B Specifications

General

Color depth	8 bit
Color gamut	72 %
Pixel pitch	490.05 x 490.05 mm
Screen shape	Flat
Response time	8 ms
Backlight type	LED
Display surface	Matt
Display diagonal	43 \
Display technology	-
Maximum refresh rate	60 Hz
Viewable size, vertical	531.02 mm
Contrast ratio (dynamic)	100000:1
Viewable size, horizontal	942.78 mm
Display brightness (typical)	500 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
USB hub version	2.0
Panel mounting interface	400 x 300 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	1 W
Power consumption (typical)	118 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Package depth	208 mm
Package width	1192 mm
Package height	752 mm
Package weight	23000 g
Cables included	AC, LAN (RJ-45)
Product color	Black

Weight and Dimensions

Bezel width (side)	28.5 mm
Bezel width (bottom)	31 mm
Depth (without stand)	78.24 mm
Width (without stand)	998.78 mm
Height (without stand)	590.52 mm
Weight (without stand)	21000 g
