HIKVISION DS-D5043FL-B User Manual

2.3 Congure Image Parameters
Image Mode
You can switch image modes and adjust image parameters including contrast, brightness, color,
sharpness, and hue.
Enter Image Mode page: MENU → Image Mode , and then press ▲or▼to select Image Mode.
Figure 2-3 Image Mode
Standard
Suitable for a normal environment.
Gentle
Suitable for a dark room.
Dynamic
Suitable for a bright room.
User
When you select the User mode, press ◄ or ► to set the brightness, contrast, color, or
sharpness to adjust display
eect.
Note
Adjustable parameters vary depending on the input source you choose. If the parameter bar is
gray, it indicates that the parameter is unadjustable under the current input source.
Backlight Sengs
You can adjust the screen brightness. The higher the backlight value, the brighter the screen.
LCD Monitor User Manual
7

HIKVISION DS-D5043FL-B Specifications

General

Color depth	8 bit
Color gamut	72 %
Pixel pitch	490.05 x 490.05 mm
Screen shape	Flat
Response time	8 ms
Backlight type	LED
Display surface	Matt
Display diagonal	43 \
Display technology	-
Maximum refresh rate	60 Hz
Viewable size, vertical	531.02 mm
Contrast ratio (dynamic)	100000:1
Viewable size, horizontal	942.78 mm
Display brightness (typical)	500 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
USB hub version	2.0
Panel mounting interface	400 x 300 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	1 W
Power consumption (typical)	118 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Package depth	208 mm
Package width	1192 mm
Package height	752 mm
Package weight	23000 g
Cables included	AC, LAN (RJ-45)
Product color	Black

Weight and Dimensions

Bezel width (side)	28.5 mm
Bezel width (bottom)	31 mm
Depth (without stand)	78.24 mm
Width (without stand)	998.78 mm
Height (without stand)	590.52 mm
Weight (without stand)	21000 g
