HIKVISION DS-D5043FL-B - 1.4 Interfaces

Figure 1-1 Panel Buons
Table 1-1 Buons Descripon
Buon Descripon
POWER Conrm
Start up
Hold down to shut down
MENU Enter main menu
SOURCE Enter source menu
▲/▼/◄/► Move the cursor up/down/le/right
1.4 Interfaces
Figure 1-2 Rear Panel of Device
Table 1-2 Descripon of Rear Panel
Interface Descripon
BNC IN CVBS input
BNC OUT CVBS output
