HIKVISION DS-D5043FL-B User Manual

Note
The following keys are only used under the USB signal source: , , , , , .
Table 1-3 Descripon of Remote Control Buons
Key Funcon
Turn on/o the monitor
Turn on/o the sound
MENU Enter/Exit main menu
FREEZE Freeze the image
SOURCE Input source selecon menu
▲/▼/◄/► Up/down/le/right direcon keys, select a submenu or set menu
parameters
OK Conrm
Play/Pause
Stop
/ Previous/Next
Repeat
Return
LCD Monitor User Manual
4

HIKVISION DS-D5043FL-B Specifications

General

Color depth	8 bit
Color gamut	72 %
Pixel pitch	490.05 x 490.05 mm
Screen shape	Flat
Response time	8 ms
Backlight type	LED
Display surface	Matt
Display diagonal	43 \
Display technology	-
Maximum refresh rate	60 Hz
Viewable size, vertical	531.02 mm
Contrast ratio (dynamic)	100000:1
Viewable size, horizontal	942.78 mm
Display brightness (typical)	500 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
USB hub version	2.0
Panel mounting interface	400 x 300 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	1 W
Power consumption (typical)	118 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Package depth	208 mm
Package width	1192 mm
Package height	752 mm
Package weight	23000 g
Cables included	AC, LAN (RJ-45)
Product color	Black

Weight and Dimensions

Bezel width (side)	28.5 mm
Bezel width (bottom)	31 mm
Depth (without stand)	78.24 mm
Width (without stand)	998.78 mm
Height (without stand)	590.52 mm
Weight (without stand)	21000 g
