HIKVISION DS-K1104MK Installation Manual

11
No.
Description
DIP
Switch Status
7
Wiegand Protocol
(available when No. 6 is 1)
1: Wiegand protocol
of 26-bit;
0: Wiegand protocol
of 34-bit.
8
Matched Resistance
(available for RS
-
485 protocol)
1: Enable;
0
:
Disable.
3.3 Definition of Cable
The description of 10 cables is shown below.
Table 3-3 Description of Cable
Color
Description
Yellow RS-485+
Brown
Blue LED Control (
ava
ilable for
Wiegand
Protocol)
Blue RS-485-
Purple
Beep Control (
available for
Wiegand
Protocol
)
Gray Case Sensor (available for Wiegand Protocol)
Green
Wiegand W0 (
available for
Wiegand
Protocol
)
White Wiegand W1 (available for Wiegand Protocol)
Black
GND
Orange Red LED Control (available for Wiegand Protocol)
Red PWR (DC +12V)
3.4 Wiring Cables
Purpose:
Wire the cables between controller and card reader, thus to
establish the communication between them.
Steps for RS-485 communication mode:

HIKVISION DS-K1104MK Specifications

General

Quantity per pack	1 pc(s)
Internal	No
Product color	Black, Silver
Built-in processor	Yes
Compatible memory cards	-
RS-485 ports	1
Type	Basic access control reader
Certification	FCC, CE
LED indicators	Status
RFID frequency	13.56 MHz
Authentication type	Access chip/card, Password
Supported protocols	Mifare
Keypad number of keys	12
RFID reading distance	50 mm
International Protection (IP) code	IP65
Operating temperature (T-T)	-20 - 65 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption	0.5 mA

Weight and Dimensions

Depth	23 mm
Width	76 mm
Height	118 mm
Weight	520 g
