HIKVISION DS-KB8113-IME1(B) Series User Manual

Chapter 2 Terminal and Wiring Descripon
2.1 Terminal Descripon
Figure 2-1 Terminals Descripon
Table 2-1
Descripon
Name No. Interface Descripon
Power Supply 1 12 VDC 12 VDC Power Supply Input
LAN 2 LAN Network Interface (PoE Supported)
ALARM IN A1 AI Alarm Input
A2 GND Grounding
ALARM OUT B1 COM Common Interface
B2 NO Door Lock Relay Output (Connect Electric Strike)
B3 NC Door Lock Relay Output (Connect Electric Bolt
or Contact Lock)
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
3
