Video Intercom Door Station·User Manual
5
Resident
Indoor Station
Network Cable
Door Station
Connect to the LAN
of Community via
Optical Fiber
Optical Fiber
Figure 3-2 Typical Application (1)
Resident 2
Resident 2
Resident 2
Resident 2
Indoor Stations
Network Cable
Doorphones
Connect to the LAN of Community
via Optical Fiber
Optical Fiber
4F
3F
2F
1F
-1F/G
Resident 1
Resident 1
Resident 1
Resident 1
Connect to Door Station/ Outer
Door Station
Figure 3-3 Typical Application (2)
