3 Typical Application
3.1 Typical Application of Door Station (DS-KV8X02-1A)
Please refer to the following figure for typical application of DS-KV8102-1A/ DS-KV8202-
1A/ DS-KV8402-1A door station.
Resident 2 Resident 1
Indoor Stations
Network Cable
Door Station
Connect to the LAN of
Community via Optical
Fiber
Optical Fiber
Main Door Station
Figure 3-1 Typical Application
3.2 Typical Application of Door Station (DS-KV8102-XC)
Please refer to the following figures for typical applications of DS-KV8102-1C/ DS-
KV8102-2C door station.
DS-KV8102-1C/ DS-KV8102-2C door station can also work as doorphone. Please refer to
the typical application (2).
