HIKVISION DS-KV8113-WME1 User Manual

DS-KV8x13-WME1 Video Intercom Villa Door Station User Manual
UM DS-KV8x13-WME1 Villa Door Station 062321NA 18
4. Activation
4.1. Activate Device via Web
You are required to activate the device first by setting a strong password for it before you can use the
device.
Default parameters of the door station are as follows:
• Default IP Address: 192.0.0.65
• Default Port No.: 8000
• Default User Name: admin
Steps
Power on the device, and connect the device to the network.
Enter the IP address into the address bar of a Web browser, and click Enter to enter the activation
page.
NOTE: The computer and the device must belong to the same subnet.
Create and enter a password into the password field.
Confirm the password.
Click OK to activate the device.
4.2. Activate Device via Client Software
You can configure and operate the door station only after creating a password for the device activation.
Default parameters of door station are as follows:
• Default IP Address: 192.0.0.65
• Default Port No.: 8000
• Default User Name: admin
Steps
Run the client software, then click Maintenance and Management → Device Management → Device to
enter the page.
Click Online Device.
Select an inactivated device, and click Activate.

HIKVISION DS-KV8113-WME1 Specifications

General

Color	Yes
Number of buttons	4 buttons
Connectivity technology	Wired
Number of displays supported	-
Megapixel	2 MP
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Viewing angle, vertical	75 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	129 °
Voice codecs	G.711u
LED type	IR
Night vision distance	3 m
Outdoor unit power type	DC
AC adapter output voltage	12 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-40 - 53 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	- \
Proper use	Outdoor
Product color	Black, Grey
Placement supported	Vertical
International Protection (IP) code	IP65
Package depth	120 mm
Package width	140 mm
Package height	220 mm
Indoor unit included	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, RSTP
