DS-KV8x13-WME1 Video Intercom Villa Door Station User Manual
UM DS-KV8x13-WME1 Villa Door Station 062321NA 29
Max. Bitrate: Set the max. bitrate from 32 to 16384 Kbps. A higher value corresponds to higher
video quality, but more bandwidth is required.
Video Encoding: The device supports H.264.
I Frame Interval: Set the I Frame Interval from 1 to 400.
Click Save to save the settings.
Audio Parameters
Steps
Click Video/Audio → Audio to enter the settings page.
Figure 25, Audio Settings
Configure the stream type and the audio encoding type.
Stream Type: Set the stream type to Main Stream or Sub Stream.
Audio Encoding: The device support G.711ulaw and G.711alaw.
Adjust the Input Volume, Output Volume, and Speak Volume.
NOTE: Available volume range: 0 to 10.
Click Save to save the settings.
5.6. Image Settings
Display Settings
Configure the image adjustment, backlight settings, and other parameters in display settings.
Steps
Click Image → Display Settings to enter the display settings page.

HIKVISION DS-KV8113-WME1 Specifications

General

Color	Yes
Number of buttons	4 buttons
Connectivity technology	Wired
Number of displays supported	-
Megapixel	2 MP
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Viewing angle, vertical	75 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	129 °
Voice codecs	G.711u
LED type	IR
Night vision distance	3 m
Outdoor unit power type	DC
AC adapter output voltage	12 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-40 - 53 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	- \
Proper use	Outdoor
Product color	Black, Grey
Placement supported	Vertical
International Protection (IP) code	IP65
Package depth	120 mm
Package width	140 mm
Package height	220 mm
Indoor unit included	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, RSTP
