HIKVISION DS-KV8202-IM User Manual

Video Intercom Door Station·User Manual
17
6 Before You Start
For the first time use of the device, you are required to activate the device. You can
activate the device and set the device password via internet with Batch Configuration
Tool, or with iVMS-4200 client software, or with Video Intercom Set-up Tool.
To activate the device with Batch Configuration Tool or iVMS-4200, refer to 7
Remote Operation via Batch Configuration Tool and 8 Remote Operation via
iVMS-4200.
Please refer to 7.1 for creating the device password.

HIKVISION DS-KV8202-IM Specifications

General

Color	Yes
Video codecs	H.264
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Number of buttons	2 buttons
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Megapixel	1.3 MP
Sensor type	CMOS
Maximum frame rate	25 fps
Maximum video resolution	1280 x 720 pixels
Proper use	Outdoor
Product color	Aluminum
International Protection (IP) code	IP65
LED type	IR
Outdoor unit power type	AC/DC
Power consumption (typical)	12 W
Operating relative humidity (H-H)	10 - 90 %
Door station operating temperature (T-T)	-40 - 70 °C
Operating system installed	Linux
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP
Indoor unit included	No

Weight and Dimensions

Depth	33 mm
Width	100 mm
Height	182 mm
Door station dimensions (WxDxH)	100 x 33 x 182 mm
