HIKVISION DS-PHA64-LP User Manual

98
5. Select the encryption type as None, SSL or TLS.
6. Enable Server Authentication.
7. Enter receiver name and receiver email address. Tap Test Receiver Email Address to test
whether the email address is correct.
8. Tap Save.
FTP Settings
Steps
1. In the site, tap the AX HYBRID PRO and then log in to the device (if required).
2. Tap → Communication Parameters→ FTP Settings to enter the page.
3. Select Preferred FTP or Alternated FTP, and enable FTP.
4. Configure the FTP parameters
FTP Type
Set the FTP type as preferred or alternated.
Protocol Type
FTP and SFTP are selectable. The files uploading is encrypted by using SFTP protocol.
Server Address and Port
The FTP server address and corresponding port.
User Name & Password/Anonymity
The FTP user should have the permission to upload pictures. If the FTP server supports
picture uploading by anonymous users, you can enable Anonymous to hide your device
information during uploading.
Directory Structure
The saving path of snapshots in the FTP server.
4. Tap Save.
NAT
Universal Plug and Play (UPnP™) is a networking architecture that provides compatibility among
networking equipment, software and other hardware devices. The UPnP protocol allows devices
to connect seamlessly and to simplify the implementation of networks in the home and corporate
environments.
Enable the UPnP function, and you don’t need to configure the port mapping for each port, and
the device is connected to the Wide Area Network via the router.
Steps
1. In the site, tap the AX HYBRID PRO and then log in to the device (if required).
2. Tap → Communication Parameters→ NAT to enter the page.
3. Drag the slider to enable UPnP.
4. Optional: Select the mapping type as Manual to set the HTTP port and the service port.

HIKVISION DS-PHA64-LP Specifications

General

Wi-Fi	Yes
Wi-Fi frequency	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Number of alarm zones	64
Connectivity technology	Wired & Wireless
Operating temperature (T-T)	-10 - 40 °C
Number of simultaneous users	62 user(s)
Operating relative humidity (H-H)	10 - 90 %
Number of simultaneously connected devices (max)	-
Batteries included	No
Number of door/window sensors	- pc(s)
Mounting type	Wall
Product color	White
Housing material	Plastic
Battery life	36 h
Alarm current	2000 mA
Input voltage	100 - 240 V
Battery voltage	12 V
Battery capacity	7000 mAh

Weight and Dimensions

Alarm control panel weight	997 g
Alarm control panel dimensions (W x D x H)	261 x 86.4 x 199 mm
