HIKVISION DS-PHA64-LP User Manual

20
Note
The administrator has two more attempts than the configured value.
Auto-lock Time
Set the locking duration when the account is locked.
Note
The available locking duration is 5s to 1800s.
3. Click to unlock the account or click Unlock All to unlock all locked users in the list.
4. Click Save.
Module Lock Settings
Set the module locking parameters, including the Max Failure Attempts, and locked duration. The
module will be locked for the programmed time duration, once the module authentication has
failed for the amount of configured times.
Steps
1. Click System → System Security → Module Locking Settings to enter the Module Lock Settings
page.
2. Select a module from the list, and click the icon.
3. Set the following parameters of the selected module.
Retry Times before Auto-Lock
If a user continuously tries to authentication a password for more than the configured
attempts permitted, the keypad will be locked for the programmed duration.
Auto-lock Time
Set the locking duration when the keypad is locked. After the configured duration, the keypad
will be unlocked.

HIKVISION DS-PHA64-LP Specifications

General

Wi-Fi	Yes
Wi-Fi frequency	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Number of alarm zones	64
Connectivity technology	Wired & Wireless
Operating temperature (T-T)	-10 - 40 °C
Number of simultaneous users	62 user(s)
Operating relative humidity (H-H)	10 - 90 %
Number of simultaneously connected devices (max)	-
Batteries included	No
Number of door/window sensors	- pc(s)
Mounting type	Wall
Product color	White
Housing material	Plastic
Battery life	36 h
Alarm current	2000 mA
Input voltage	100 - 240 V
Battery voltage	12 V
Battery capacity	7000 mAh

Weight and Dimensions

Alarm control panel weight	997 g
Alarm control panel dimensions (W x D x H)	261 x 86.4 x 199 mm
