PanoVu Series Camera·Quick Start Guide
Figure 1-14 Install the Safety Rope
7. Connect all cables and insert the rest cables into the bracket.
8. Fix the PanoVu camera with the head cover by fixing screws of the head cover and bracket,
as shown in Figure 1-15.
Figure 1-15 Fix the PanoVu Camera
2.2.2 Installing the 360° Panoramic + PTZ Camera
Steps:
1. Loosen the two lock screws on the both side of the camera. Pull the lower camera to
separate it from the back box as shown in Figure 1-16.
Please do not remove the lock screws from the camera.
