10 English
3.1.2 Saw trolley (accessory)
@
Grip
;
Throttle trigger
=
Cutting depth adjustment
%
Hold-down device
&
Water tank
(
Water connection
)
Axial adjustment
+
Throttle cable
§
Machine cradle
3.2 Intended use
The product described is a gasoline-powered cut-off saw for the wet or dry cutting of asphalt, mineral
construction materials or metals using diamond cutting discs or abrasive cutting discs. It can be held and
guided by hand or mounted on a saw trolley.
The saw is not suitable for use in environments where there is risk of fire or explosion.
Printed: 24.04.2018 | Doc-Nr: PUB / 5265931 / 000 / 02
