1.3 Product-dependent symbols
1.3.1 Symbols on the product
The following symbols are used on the product:
Direction-of-rotation arrow on the guard
Engine stop position
Engine run position
Primer bulb
Idling jet adjusting screw
Full-throttle jet adjusting screw
Idling adjusting screw
Fuel mixture
Fuel-tank cap opening direction
Choke (not -X)
Half throttle (not -X)
Wear ear protection, eye protection, respiratory protection and a hard hat
Wear protective gloves
Wear protective footwear
Wireless data transfer
1.4 Adhesive labels on the machine
Warning signs
Warning: Risk of fire due to flying sparks
Warning: Risk of kickback
Warning: Do not inhale toxic vapors or exhaust fumes
Maximum spindle speed
Warning: Hot surface
Prohibition symbols
Do not use toothed cutting discs
Do not use damaged cutting discs
No smoking, no naked flame
