8 English 2153714
*2153714*
Status Meaning
1 LED lights. Charge status: 10 % to 25 %
1 LED blinks, the power tool is ready for use. Charge status: < 10 %
1 LED blinks, the power tool is not ready for use. The battery has overheated or is completely dis-
charged.
4 LEDs blink, the power tool is not ready for use. The power tool is overloaded or has overheated.
Battery charge status cannot be displayed while the control switch is pressed and for up to 5 seconds
after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given in the Troubleshooting section.
3.4 Fence
Use of the single arm fence allows precise cuts to be made along the edge of the workpiece, or strips of
even width to be cut.
The fence can be fitted on either side of the base plate.
3.5 Items supplied
Circular saw, saw blade, hex key, fence, vacuum cleaner hose connector, operating instructions.
Spare parts, consumables and accessories approved by Hilti for use with the product can be found at
your local Hilti Store or online at: www.hilti.group | USA: www.hilti.com
3.6 Accessories
Clamping flange, mounting flange, clamping screw.
4 Technical data
4.1 Circular saw
SCW 22-A
Rated voltage
21.6 V
Weight
9.0 lb
(4.1 kg)
Specified blade diameter
6.3 in … 6.5 in
(160 mm … 165 mm)
Blade disc thickness
0.02 in … 0.06 in
(0.5 mm … 1.5 mm)
Kerf width
0.06 in … 0.1 in
(1.5 mm … 2 mm)
Saw blade arbor size
0.8 in
(20 mm)
Rated speed under no load
4,000 /min
Maximum cutting depth
2.2 in
(57 mm)
Bevel cutting angle
0° … 50°
Operating temperature
1 ℉ … 140 ℉
(−17 ℃ … 60 ℃)
Storage temperature range (without battery)
−4 ℉ … 158 ℉
(−20 ℃ … 70 ℃)
