Hilti SCW 22-A Original Operating Instructions

English 17
6.1 Cleaning the safety guard
1. Remove the saw blade before cleaning the safety guard parts.
2. Clean the safety guard parts carefully with a dry brush.
3. Use a suitable tool to remove deposits or cuttings from the inside surfaces of the safety guard parts.
4. Fit the saw blade.
6.2 Checks after cleaning and maintenance
After cleaning or maintenance, check that all safety devices are fitted and that they function faultlessly.
▶ To check the pivoting guard, open the guard fully by moving the guard operating lever.
➥ The pivoting guard must close quickly and completely when the guard operating lever is released.
7 Transport and storage of cordless tools
Transport
CAUTION
Accidental starting during transport !
▶ Always transport your products with the batteries removed!
▶ Remove the battery.
▶ Never transport batteries in bulk form (loose, unprotected).
▶ Check the tool and batteries for damage before use after long periods of transport.
Storage
CAUTION
Accidental damage caused by defective or leaking batteries !
▶ Always store your products with the batteries removed!
▶ Store the tool and batteries in a place that is as cool and dry as possible.
▶ Never store batteries in direct sunlight, on heating units or behind a window pane.
▶ Store the tool and batteries in a place where they cannot be accessed by children or unauthorized
persons.
▶ Check the tool and batteries for damage before use after long periods of storage.
8 Troubleshooting
▶ If the trouble you are experiencing is not listed in this table or you are unable to remedy the problem by
yourself, please contact Hilti Service.
8.1 The circular saw is not in working order.
Malfunction Possible cause Action to be taken
The LEDs indicate nothing. The battery is not fully inserted. ▶ Insert the battery.
The battery is discharged. ▶ Charge the battery.
The battery is too hot or too cold. ▶ Bring the battery to the correct
ambient temperature.
1 LED blinks. The battery is discharged. ▶ Charge the battery.
The battery is too hot or too cold. ▶ Bring the battery to the correct
ambient temperature.
4 LEDs blink. The circular saw was overloaded
briefly.
▶ Release the control switch and
then press it again.
The overheating prevention cut-out
has been activated.
▶ Allow the circular saw to cool
down to cool down and clean
the air vents.
Printed: 24.05.2019 | Doc-Nr: PUB / 5292954 / 000 / 01

Hilti SCW 22-A Specifications

General

Blade diameter	165 mm
Idle speed (max)	4000 RPM
Cutting depth (45º)	42 mm
Cutting depth (90º)	57 mm
Sound pressure level	93 dB
Vibration level (wood cutting)	1.2 m/s²
Product color	Black, Red
Country of origin	Germany
Dust extraction port	Yes
Power source	Battery
Diamond disc	-
Battery included	No
Quantity per shipping (inner) case	1 pc(s)

Weight and Dimensions

Package depth	898 mm
Package width	5400 mm
Package height	2000 mm
Package weight	1345 g
