*2231428*
2231428 English 9
5.7 Installing the Hilti retaining strap (optional) 5
ATTENTION
Damage to the product and / or the retaining leash. Incorrect handling can result in damage to the
product and/or retaining leash.
▶ Do not use a metal chain as a retaining leash. Do not use a retaining leash with a length of more than
2,0 m (6 ft).
To avoid damage and injury, when working at a height it is advisable to use the Hilti retaining strap.
The retaining strap allows a securing cord or lanyard to be attached.
When working with the product, you must comply with national regulations for working at heights.
1. Remove the battery. → page 8
2. Insert the two tabs on the retaining strap into the slots on each side of the base.
3. Secure the retaining strap with the screws supplied.
4. Insert the battery. → page 8
5.8 Selecting the gear 6
▶ Select the gear.
5.9 Setting forward or reverse rotation 7
An interlock prevents switching while the motor is running.
The control switch is locked when the forward/reverse switch is in the middle position (safety lock).
▶ Set the forward/reverse selector switch to forward or reverse rotation, as applicable.
5.10 Inserting / removing the accessory tool 8
1. Set the forward/reverse switch to the middle position or remove the battery from the power tool.
2. Open the keyless chuck.
3. Insert the accessory tool into the chuck or remove it from the chuck.
4. Tighten the keyless chuck.
5. Check that the accessory tool is held securely.
5.11 Drilling 9
CAUTION
Risk of injury. The accessory tool may suddenly stall, causing the power tool to rotate about its own axis.
▶ Use the power tool with the side handle fitted and always hold it securely with both hands.
▶ Always grip the side handle at its outermost end.
CAUTION
Risk of injury. Risk of flying fragments.
▶ Wear eye protection.
▶
Set the torque and operating mode selector ring to the “Drilling” symbol .
