Hilti SF 6H-A22 User Manual

English 11
@
Pivotable side handle
;
Chuck (keyless chuck / hex bit
holder)
=
Torque and operating mode
selector ring
%
Two-speed gear selector
switch
&
Forward / reverse selector
switch with safety lock
(
Control switch (with electronic
speed control)
)
Vibration-absorbing grip
+
Illumination
§
Belt hook (optional)
/
Battery
:
Charge state and fault display
(Li-ion battery)
∙
Release button with additional
function (charge state display
activation)
3.2 Intended use
The product described is a hand-held cordless drill / driver. It is designed for
drilling in steel, wood, plastic, cellular concrete and masonry and for driving
and removing screws.
▶ Use this product only with Hilti Liion batteries of the B18 / B22 series.
▶ Use only Hilti battery chargers of the C4/36 series with these batteries.
3.3 Items supplied
Drill / driver, side handle, operating instructions.
You can find other system products approved for your product at your local
Hilti Center or online at: www.hilti.com
3.4 Li-ion battery state of charge display
The Li-ion battery state of charge and malfunctions of the power tool are
indicated by the display on the Liion battery. The Liion battery state of
charge is displayed after pressing one of the two battery release buttons.
Status Meaning
4 LEDs light. • Charge state: 75 % to 100 %
3 LEDs light. • Charge state: 50 % to 75 %
2 LEDs light. • Charge state: 25 % to 50 %
1 LED lights. • Charge state: 10 % to 25 %
1 LED blinks, the power tool is
ready for use.
• Charge state: < 10 %
1 LED blinks, the power tool is not
ready for use.
• The battery has overheated.
4 LEDs blink, the power tool is not
ready for use.
• The power tool has overheated or
is overloaded.
Printed: 01.02.2017 | Doc-Nr: PUB / 5329076 / 000 / 00

Hilti SF 6H-A22 Specifications

General

Reverse	Yes
Handle shape	Pistol handle
Product type	Power screwdriver
Product color	Black, Red
Country of origin	Germany
Number of gears	2
Idle speed (max)	1480 RPM
Idle speed (min)	1600 RPM
Screw diameter (max)	13 mm
Maximum torque (hard applications)	80 N⋅m
Maximum torque (soft applications)	50 N⋅m
Noise level	84 dB
Vibration emission	2 m/s²
Power source	Battery
Battery included	No
Quantity per shipping (inner) case	1 pc(s)

Weight and Dimensions

Depth	212 mm
Width	92 mm
Height	210 mm
Weight	1580 g
Package depth	980 mm
Package width	1005 mm
Package height	2000 mm
Package weight	5956 g
