8 English
@
Dust shield
;
Chuck
=
Accessory tool release
%
Function selector switch
&
Depth gauge
(
Forward / reverse selector switch with
safety lock
)
Control switch
+
Grip
§
Battery
/
Charge state and fault display (Li-ion
battery)
:
Battery release buttons
∙
Connection for the TE DRS-4-A(01) dust
removal module
$
Side handle
3.2 Intended use
The product described is a battery-powered rotary hammer. It is designed for hammer drilling in concrete
and masonry, for drilling in steel, wood and masonry and for driving and removing screws.
▶ Use only Hilti lithiumion batteries of the B 22 series with this product.
▶ Use only Hilti battery chargers of the C4/36 series for charging these batteries.
3.3 Lithiumion battery status display
When the lithium-ion battery is used the charge status can be displayed by tapping one of the battery release
buttons.
Status Meaning
4 LEDs light. Charge status: 75 % to 100 %
3 LEDs light. Charge status: 50 % to 75 %
2 LEDs light. Charge status: 25 % to 50 %
1 LED lights. Charge status: 10 % to 25 %
1 LED blinks. Charge status: < 10 %
Indication of the charge status is not possible while the power tool is in operation or immediately after
operation. If the battery charge status LEDs flash, please refer to the information given in the Troubleshooting
section.
3.4 Items supplied
Rotary hammer, side handle, depth gauge, operating instructions.
The TE DRS-4-A (01) dust removal module is available as an accessory that greatly reduces dust emissions.
You can find other system products approved for your product at your local Hilti Center or online at:
www.hilti.com.
4 Technical data
4.1 Rotary hammer
TE 4A22
Weight in accordance with EPTA Procedure 01 including B22⁄8.0 battery
3.9 kg
Single impact energy in accordance with EPTA procedure 05/2009
2 J
Drilling diameter range in concrete/masonry (hammer drilling)
5 mm … 16 mm
Drilling diameter range in wood (solid)
3 mm … 20 mm
Drilling diameter range in metal (solid-head drill bit)
3 mm … 10 mm
4.2 Noise information and vibration values
The sound pressure and vibration values given in these instructions have been measured in accordance
with a standardized test and may be used to compare one electric tool with another. They may be used
for a preliminary assessment of exposure. The data given represents the main applications of the electric
tool. However, if the electric tool is used for different applications, with different accessory tools, or is poorly
maintained, the data may vary. This may significantly increase exposure over the total working period. An
accurate estimation of exposure should also take into account the times when the power tool is switched
off, or when it is running but not actually being used for a job. This may significantly reduce exposure over
the total working period. Identify additional safety measures to protect the operator from the effects of noise
Printed: 10.04.2019 | Doc-Nr: PUB / 5200339 / 000 / 03
