ORIGINAL OPERATING INSTRUCTIONS
TE 70 / TE 70-D / TE 70-ATC/-AVR / TE 80 / TE 80-ATC/-AVR
combihammer
It is essential that the operating instructions
are read before the power tool is operated for
the first time.
Always keep these operating instructions to-
gether with the power tool.
Ensure that the operating instructions are
with the power tool when it is given to other
persons.
Contents Page
1 General information 1
2Description 2
3 Insert tools, accessories 4
4 Technical data 4
5 Safety instructions 5
6Beforeuse 7
7 Operation 7
8 Care and maintenance 9
9 Troubleshooting 10
10 Disposal 11
11 Manufacturer’s warranty - tools 11
1 These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out cover
pages. Keep these pages open while studying the oper-
ating instructions.
In these operating instructions, the designation “the
power tool” always refers to the TE 70-D/AVR rotary ham-
mer or TE 70-AVR, TE 70-ATC/AVR or TE 80-ATC/AVR
combihammer.
TE 70-ATC/AVR and TE 80-ATC/AVR 1
@
Function selector switch
;
Control switch lock
=
Control switch
%
Supply cord
&
Button for 50% power reduction (only ATC combi-
hammers)
(
Side handle
)
Chuck
+
Dust shield
§
Insert tool unlocking device
/
Service indicator
:
Reduced-power indicator (only ATC combiham-
mers)
TE 70-D/AVR and TE 70/AVR 2
@
Function selector switch (only combihammers)
;
Control switch lock (only combihammers)
=
Control switch
%
Supply cord
(
Side handle
)
Chuck
+
Dust shield
§
Insert tool unlocking device
/
Service indicator
1 General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that will lead to
seriousbodilyinjuryorfatality.
WARNING
Draws attention to a potentially dangerous situation that
could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that
could lead to slight personal injury or damage to the
equipment or other property.
NOTE
Draws attention to an instruction or other useful informa-
tion.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
Warning:
electricity
Warning: hot
surface
