3 Insert tools, accessories
Insert tools
Designation Description
Hammer drill bits ∅ 12…45 mm (0.47…1.77")
Breach bits ∅ 40…80 mm (1.57…3.15")
Percussion core bits ∅ 45…150 mm (1.77…5.91")
PCM diamond core bits ∅ 42…132 mm (1.65…5.2")
Chisels Pointed, flat and shaped chisels with TE‑Y connection
end
Wood drill bits ∅ 10…32 mm (0.39…1.26")
Metal drill bits Up to ∅ 20 mm (0.79")
Depth gauge
TE-FY-BA-C adapter
TE-Y-AD adapter
Dust modules TE DRS-BK,TE DRS-B, TE DRS-S
Accessories
Designation Item number, description
Setting tool 32221, Setting tool with TE‑Y connection end
Quick-release chuck 60208, Keyless chuck for wood and metal drill bits with
smooth or hex. shank, Chuck holder 263359
Mixing paddles,with smooth or hex. shank, for mixing
non-flammable, non-hazardous substances
41215 (∅80mm), 41216 (∅110mm), ∅ 80…150 mm
(3.15…5.91"), For use only with the keyless
quick-release chuck
4 Technical data
Right of technical changes reserved.
Power tool TE 70-D/AVR TE 70‑AVR
TE 70-ATC/AVR TE 80-ATC/AVR
Weight 8.3 kg (18.3 lb) 8.3 kg (18.3 lb) 9.5 kg (20.94 lb) 9.7 kg (21.38 lb)
Dimensions (L ×
W×H)
536 mm (21.1") ×
126 mm (4.96") ×
305.5 mm (12.03")
536 mm (21.1") ×
126 mm (4.96") ×
305.5 mm (12.03")
536 mm (21.1") ×
126 mm (4.96") ×
324 mm (12.76")
549 mm (21.61") ×
126 mm (4.96") ×
324 mm (12.76")
Power tool TE 70-D/AVR TE 70‑AVR
TE 70-ATC/AVR TE 80-ATC/AVR
Rated voltage 120 V 120 V 120 V 120 V
Rated current input 15 A 15 A 15 A 15 A
Mains frequency 60 Hz 60 Hz 60 Hz 60 Hz
Hammer drilling
speed
360/min 360/min 360/min 360/min
Single impact en-
ergy (full power)
11.5 J 11.5 J 11.5 J 11.5 J
Other information about the power tool
ATC electronic cut-out TE 70‑ATC/ TE 80‑ATC
Protection class Protection class II (double insulated)
en
4
