2.2 Chuck
TE‑Y (SDS max) quick-change “click” chuck
2.3 Switches
Speed control switch for smooth starting
Combihammer function selector switch: Hammer drilling, chiseling, chisel adjustment (24 positions – depends on
version)
Selector for full or reduced (50%) power (depends on version)
Control switch locking mechanism which can be locked for chiseling (depends on version)
2.4 Grips
Vibration-absorbing, pivotable side handle
Vibration-absorbing grip
2.5 Protective devices
Mechanical safety clutch
Electronic restart interlock to prevent the power tool starting unintentionally after an interruption in the electric supply
(see section 9 “Troubleshooting”).
Additional ATC “Active Torque Control” (TE 70‑ATC/AVR and TE 80‑ATC/AVR)
2.6 Lubrication
Gearing and hammering mechanism with separate lubrication chambers
2.7 Active Vibration Reduction
The tool is equipped with the “Active Vibration Reduction” (AVR) system, which significantly reduces vibration.
TE 80-ATC/AVR also has a handle damping system.
2.8 LED indicators
Service indicator LED (see section “Care and maintenance”)
Reduced-power indicator (depends on version): (Please refer to the “Operation” section.)
2.9 Items supplied
1 Power tool
1Sidehandle
1 Grease
1 Cleaning cloth
1 Operating instructions
1 Hilti toolbox
2.10 Using extension cords
Recommended minimum conductor cross section and max. cable lengths
Conductor cross section 14 AWG 12 AWG
Mains voltage 110-127 V 75 ft 150 ft
2.11 Using a generator or transformer
This power tool may be powered by a generator or transformer when the following conditions are fulfilled: The unit
must provide a power output in watts of at least twice the value printed on the type identification plate on the power
tool. The operating voltage must remain within +5% and -15% of the rated voltage at all times, frequency must be in
the 50 – 60 Hz range and never above 65 Hz, and the unit must be equipped with automatic voltage regulation and
starting boost.
Never operate other power tools or appliances from the generator or transformer at the same time. Switching other
power tools or appliances on and off may cause undervoltage and / or overvoltage peaks, resulting in damage to the
power tool.
en
3
